Defective, for tinkerers/hobbyists: Skywatcher AZ-EQ5 GoTo Mount - head without tripod

Name: Defective, for tinkerers/hobbyists: Skywatcher AZ-EQ5 GoTo Mount - head without tripod
Brand: Skywatcher
SKU: 2025-0303-2
Price: 599 EUR

The Skywatcher AZEQ5Goto Synscan mount is a transportable altazimuth AND GoTo mount - perfect for Astrophotography and observing.

#AZ-EQ5-HEAD: Defective, for hobbyists: the board is loose, the hand controller shows the error ?no link to mount? - without function, with signs of use. Scope of delivery: only mount head, no counterweight, no cables

This new mount from Skywatcher is a fully functional computerised Go-To astronomical mount with precise tracking for astrophotography but also well designed for visual use.

Here we offer the mount head without tripod for everyone, who prefer another tripod than the original one. Each EQ5 and Vixen GP compatible tripod will fit this mount. We suggest the BERLEBACH UNI Astro tripods from Germany (image left)

Load capacity 15 kg

SynScan GoTo System with 42.900 objects in the database

Altazimuth AND equatorial mode both with precise tracking

Toothed belt instead of gear wheels - thus more even power transmission and reduction of gear backlash

Dual encoder for manual movement without loosing its positional information

Manufacturer: Skywatcher

Product number: 2025-0303-2

EUR 599,00RRP EUR 1.635,00you save 63.4% (EUR 1.036,00)

incl. 19 % VAT (DE)

The VAT indicated refers to that applicable in Germany. After logging in, the VAT amount is adjusted to the applicable VAT of the stored delivery country. Therefore, the final price may vary accordingly.

excl. 8.95 € shipping costs (DE)

Please log in to calculate shipping costs to your country.

more details to the shipping costs ...

There are no reviews for this product

Roll over image to zoom in or klick it. The appropriate zoom factor ist adjustable with the mouse wheel.

Defective, for tinkerers/hobbyists: Skywatcher AZ-EQ5 GoTo Mount - head without tripod

The Skywatcher AZEQ5Goto Synscan mount is a transportable altazimuth AND GoTo mount - perfect for Astrophotography and observing.

#AZ-EQ5-HEAD: Defective, for hobbyists: the board is loose, the hand controller shows the error ?no link to mount? - without function, with signs of use. Scope of delivery: only mount head, no counterweight, no cables

This new mount from Skywatcher is a fully functional computerised Go-To astronomical mount with precise tracking for astrophotography but also well designed for visual use.

Load capacity 15 kg

SynScan GoTo System with 42.900 objects in the database

Altazimuth AND equatorial mode both with precise tracking

Toothed belt instead of gear wheels - thus more even power transmission and reduction of gear backlash

Dual encoder for manual movement without loosing its positional information

Details..
Technical data..
In the box..
Manufacturer infos..
Safety informations..

The Skywatcher AZ-EQ5GT is the perfect solution for amateur astronomers who want the benefit of an altazimuth AND a equatorial GoTo mount without disadvantages of them.

In altazimuth mode, it is primarily intended for visual use, and in this mode, two telescopes can be mounted simultaneously in parallel. In equatorial mode, the AZ-EQ5GT is a wonderful base for astrophotography with precise tracking and autoguiding connection.

The mount itself only weighs 7.7 kg so it is very transportable.

Supplied with the Synscan computerised handset with dual AZ/EQ firmware, it can automatically find and track over 42,900 celestial objects from its database - in both modes - azimutal and equatorial.

Important note about power supply:

To avoid loss of warranty, please use only the power supplies and mobile supplies recommended by us. Especially simple car batteries or sealed lead-acid batteries can lead to an under-supply, which can then damage the sensitive electronics of the mount. Operating a Skywatcher GoTo mount with a non-proprietary power supply not recommended by us is at your own risk. Thank you for your understanding. Here is the link to more information: Notes_power_supply_SK_GoTo_en.pdf

Payload Capacity:	15 kg (EQ Mode) or 15 kg+15 kg (Alt-Az Dual-Mode)
Latitude Adjustment Range:	0-90°
Azimuth Adjustment Range:	Approx 15°
Weight (excl. tripod & counterweights):	7.7 kg
Counterweights:	2 x 3.5 kg
Dovetail Saddles:	2 x 45 mm (Accepts Sky-Watcher/Vixen type Dovetail Bars)
Counterweight Bar:	18 mm Diameter, Length 162 mm + 120 mm Extension
Motors:	1.8° Hybrid Stepper Motors
Transmission:	135
Gear Ratio:	810
Resolution:	5184000 Counts/Rev (approx. 0.25 arc-second)
Maximum Slewing Speed:	3.4°/second
Tracking Rates:	Sidereal, Solar and Lunar
Tracking Mode:	Equatorial or Alt-Azimuth
Auto-Guiding Speed:	0.125x, 0.25x, 0.5x, 0.75x & 1x
Whisper Quiet Slewing:
PPEC Control in EQ Mode:
DSLR Electronic Shutter Release Ports:	2
Autoguider Interface:	Yes
USB Interface:	Yes
Hand Controller:	Synscan (42,900+ Object Database)
Polar Alignment:	Via Software Control (Polar Scope optional)
Pointing Accuracy:	Up to 5 Arc-Minutes (RMS)
Resolution of Aux R.A./Dec Axis Encoders:	5144 Counts/Rev., approx. 4.2 Arc-Minutes
Power Requirement:	DC 11-16 V 2 A (7 Ah or 17 Ah Power Tank Recommended)

AZ-EQ5GT Mount - ready for azimutal and equatorial use

Manufacturer / Importeur:	Optical Vision Limited
Street:	Duracher Straße 11
ZIP / City:	87437 Kempten
Country:	Germany
Telefon number:	+49 831 697288210
Email:	accounts@opticalvision.co.uk
Website:	www.opticalvision.co.uk
