Aperture: | 150 mm |
Focal length: | 1800 mm |
Focal ratio: | f/12 |
Limiting visual magnitude: | 13m2 |
Resolution: | 0.77" |
Central obstruction: | approx. 45 mm |
Focusing: | Easy, precise internal focusing |
Connection to mount: | photo tripod connection and GP style dovetail bar |
Eyepiece side connection: | 2" and 1.25" |
Thread on the backside of the tube: | 2" SC thread |
Baffle tube: | 30 mm clear aperture |
OTA length: | 40 cm |
OTA diameter: | 18.3 cm |
Front ring diameter: | 190/191 mm |
OTA weight: | 5.3 kg |
Mount type: | Alt-azimuth, single-arm fork mount |
Equatorial wedge for using the mount in EQ mode: | Optional |
Payload capacity: | 12 kg |
Controllable by: | Wi-Fi, Bluetooth or supplied SynScan handset |
Connection Sockets: | USB-B, autoguider, SynScan handset, power jack input (5.5/2.1 mm barrel connector) |
Control: | Free SynScan or SynScan PRO Apps for iOS and Android mobile device or Synscan handset (included) |
Hand controller: | SynScan AZ computerised handset with 42,900+ objects |
Handset database: | Contains full Messier, NGC and IC catalogues |
SynScan App database: | Total 10,000+ objects with 10759 deep sky objects (including Messier, NGC, IC, Caldwell catalogues), named DSOs, 305 named star, 55 double stars, 7 solar system objects (7 planets, Sun, Moon). Unlimited objects when working with a 3rd party planetarium software. |
SynScan app alignment method: | 1-star alignment, 3-star alignment, brightest star alignment, north-level alignment |
SynScan App´s other features: | Tonight´s Best Sky tour, Point and Go with a mobile device, identification of celestial objects, remote control over internet, user defined objects, Pointing Accuracy Enhancement (PAE) |
Powered by: | Either internal rechargeable lithium-ion battery 9.6 V 45 Ah or 12-15 volt DC 3 A external power supply (not supplied) |
Tracking operation time using internal battery: | Up to 10 hours |
Telescope connection: | 45 mm / 75 mm dual-fit dovetail saddle |
Locking clutches: | Yes, on both altitude and azimuth axis |
Transmission: | Stepper motors with worm gear mechanism |
Number of teeth of the worm wheel: | 180 (both axes) |
Tripod: | Stainless steel tripod with accessory tray |
Mount head dimensions: | 335 mm x 214 mm x 467 mm |
Overall mount weight with tripod: | 8 kg |
