TS-Optics 60 mm Guide Scope with non-rotating Helical Focuser

Name: TS-Optics 60 mm Guide Scope with non-rotating Helical Focuser
Brand: -TS Zubehör
SKU: TSL60-HELI
Price: 189 EUR

This compact telescope can be used very well as a guiding telescope. With the lockable helical focuser you can easily focus and secure the setting reliably.

60 mm aperture, 240 mm focal length

1.25" focuser with T2 thread allows connection of all common cameras, autoguiders and eyepieces

Focusing with sliding tube (35mm) and fine adjustment with non-rotating helical focuser (10mm) - all clampable

Fits all standard finder shoes from Skywatcher, Vixen, GSO, Celestron, etc.

Solid construction completely made of metal - excellent for long time exposures - even with heavier guiding cameras nothing bends

Weight approximately 900 g

Manufacturer: -TS Zubehör

Product number: TSL60-HELI

EUR 189,00

incl. 19 % VAT (DE)

The VAT indicated refers to that applicable in Germany. After logging in, the VAT amount is adjusted to the applicable VAT of the stored delivery country. Therefore, the final price may vary accordingly.

excl. 6.95 € shipping costs (DE)

Please log in to calculate shipping costs to your country.

more details to the shipping costs ...

There are no reviews for this product

Roll over image to zoom in or klick it. The appropriate zoom factor ist adjustable with the mouse wheel.

TS-Optics 60 mm Guide Scope with non-rotating Helical Focuser

This compact telescope can be used very well as a guiding telescope. With the lockable helical focuser you can easily focus and secure the setting reliably.

60 mm aperture, 240 mm focal length

1.25" focuser with T2 thread allows connection of all common cameras, autoguiders and eyepieces

Focusing with sliding tube (35mm) and fine adjustment with non-rotating helical focuser (10mm) - all clampable

Fits all standard finder shoes from Skywatcher, Vixen, GSO, Celestron, etc.

Solid construction completely made of metal - excellent for long time exposures - even with heavier guiding cameras nothing bends

Weight approximately 900 g

Details..
Technical data..
In the box..

TS-Optics 60 mm Guide Scope with non-rotating Helical Focuser

This compact guide scope is a top-guality solution for all astrophotographers who need a compact guide scope but don´t want a piggyback configuration. The TSL60-HELI from TS Optics fits directly into the standard finder base of your telescope, thus mounting is really easy. If you do not like to remove your finder or if you do not have a standard finder base, we offer suitable bracket shoes in the accessories section, like one for the adaption to a tube ring.

The TSL60-HELI offers accurate tracking up to to 1000 mm focal length of the imaging optics. With special autoguiders which work in the sub-pixel range, even focal distances up to 1500 can be tracked.

Advantages and features of the TSL60-HELI:

Non-rotating helical focuser with 43 mm travel

Reliable locking of the focuser position - no bending even with heavy guiding cameras

1.25" clamping (compression ring with 2 knurled screws) AND T2 connection thread allows for versatile adaption.

Focus position suitable for all autoguiders and crosshair eyepieces

Solid all-metal design for maximal stability

High-quality manufactured, adjustable metal tube rings allows for a wide adjustment range

Finder bracket matching standard finder bases like the ones from Vixen, Skywatcher, GSO, Celestron ...

Aperture:	60 mm
Focal length:	240 mm (f/4)
Focusing distance:	35 mm coarse, 10 mm fine
Focus point:	40mm from T2 thread (inner focus position)
Camera mount:	1.25" + T2 male thread
Dovetail rail:	For standard finder shoes (Vixen, Skywatcher, GSO and similar)
Dew shield diameter:	69 mm
Tube diameter:	66 mm
Tube length:	270 mm
Material:	Aluminum
Weight:	approx. 900 g (incl. tube rings + dovetail)
