Vixen Focal Reducer V0.71X for VSD90ss and VSD70ss

Name: Vixen Focal Reducer V0.71X for VSD90ss and VSD70ss
Brand: Vixen
SKU: X026638
Price: 1249 EUR

Focal length reducer for VSD90ss and VSD70ss telescopes with two ED lenses for high-end astrophotography

Elaborately designed focal length reducer with four lens elements in four groups for exceptionally sharp star images

Suitable for a 24x36 full-frame format camera

Improves the focal ratio of the VSD90ss or VSD70SS from f/5.5 to f/3.9

Guarantees a large illumination of the image field up to 44 mm

Very sharp stars up to the edge of the field of view

The VSD astrograph with reducer allows extremely short exposure times

High-quality standard ´Made in Japan´

Dimensions: 92 mm diameter x 59.2 mm length / weight: 589 g

Manufacturer: Vixen

Product number: X026638

EUR 1.249,00

incl. 19 % VAT (DE)

The VAT indicated refers to that applicable in Germany. After logging in, the VAT amount is adjusted to the applicable VAT of the stored delivery country. Therefore, the final price may vary accordingly.

excl. 6.95 € shipping costs (DE)

Please log in to calculate shipping costs to your country.

more details to the shipping costs ...

There are no reviews for this product

Roll over image to zoom in or klick it. The appropriate zoom factor ist adjustable with the mouse wheel.

Vixen Focal Reducer V0.71X for VSD90ss and VSD70ss

Focal length reducer for VSD90ss and VSD70ss telescopes with two ED lenses for high-end astrophotography

Elaborately designed focal length reducer with four lens elements in four groups for exceptionally sharp star images

Suitable for a 24x36 full-frame format camera

Improves the focal ratio of the VSD90ss or VSD70SS from f/5.5 to f/3.9

Guarantees a large illumination of the image field up to 44 mm

Very sharp stars up to the edge of the field of view

The VSD astrograph with reducer allows extremely short exposure times

High-quality standard ´Made in Japan´

Dimensions: 92 mm diameter x 59.2 mm length / weight: 589 g

Details..
Technical data..
In the box..
Manufacturer infos..
Safety informations..

Vixen Focal Reducer V0.71X for VSD90ss and VSD70ss

Focal length reducer for the VSD90ss and VSD70ss telescopes with two ED lenses designed for high-end astrophotography

The two ED elements maximise the photographic performance of the VSD90ss and the VSD70ss, which are designed for both photography and visual observation. The reducer can illuminate an image circle of 44 mm (suitable for a 34x36 full-frame format).

The reducer has a very sophisticated design as it contains four elements in four groups, including 2 ED elements. Thanks to its larger lens diameter, it offers significantly improved image illumination compared to its predecessor, the smaller V0.79x reducer. The star distortion at the edges is also reduced to an absolute minimum.

The focal length of the VSD90ss or VSD70ss telescope is shortened to about 0.71x and the focal ratio is improved from f/5.5 to f/3.9. This results in a super-fast f/3.9 astrograph, capable of fully illuminating a full-frame DSLR camera.

Magnification:	0.71x
Focal length VSD90ss:	from 495 mm (f/5.5) to 351 mm (f/3.9)
Focal length VSD70ss:	from 385 mm (f/5.5) to 273 mm (f/3.9)
Illumination:	44 mm
Optical design:	4 elements in 4 groups, including 2 ED elements
Coatings:	AS coatings (99% light transmission per surface)
Connection thread telescope side:	M84x1 male thread
Connection thread camera side:	M60x0.75 female thread
Filter thread:	60 mm diameter
Mount material:	Aluminum
Dimensions:	D=92 mm, L=59.2 mm
Weight:	589 g

- Fokal Reducer V0.71X
- 2 mm Allen key
- Dust caps
