TS-Optics 8" f/4.5 ONTC Carbon Tube Newtonian telescope - fully customizable

ONTC Newtonian Telescopes from Teleskop Service are a unique system on the market

You choose the components and the bias of your telescope and get a Newtonian without compromises for reaching your astronomical goals. Just tell us what you want to do with the telescope and we make it according to your needs.

The ONTC Newtonian with 203 mm aperture and 900 mm focal length:

The strengths of this telescope are compactness and transportability. Astrophotographers will appreciate the Newtonian for the high speed of f/4.5. With suited correctors, the speed can be increased to f/3.3. The ONTC is very compact and also good for moon and planets. It is a real allround-telescope.

The advantages of the ONTC telescopes in short:

Optimized configuration for astrophotographic or visual use by choosing different focusers, focus positions or secondary mirror

Exchange of the secondary without problems - anytime

Only selected optics are used. Also the functionality of the optical and mechanical components are tested before sending out the ONTC.

Each ONTC Newtonian telescope comes with a complete manufacturing protocol including star test.

The edge of the secondary is blackened against reflexes and false light.

The carbon tube is made in Germany. It is manufactured in a carbon/rigid foam sandwich construction for a perfect stability at an unbeatable weight ratio

Fantastic temperature compensating performance - barely any temperature based focus drift

The mirror cells are manufactured in Germany, too. The telescope can be collimated completely without tools.

One telescope, many focal distances - due to different correctors! The correctors need different focus positions above the focuser. The tube offers three positions of the primary mirror cell.

TS "Black" anti-reflective paint for maximum contrast

Many of our UNC and all ONTC Newtonian telescopes use the TS-Optics "Black" anti-reflective paint. It darkens the inside of the tube just as well as velour foil. The illustration shows how dark the anti-reflective paint is. The diagram (at the images at the top of this page) shows the direct comparison between the commonly used chalkboard paint and the anti-reflective paint.

Choose a suitable focuser in the "options" list

The free choice of the focuser makes the ONTC Newtonians unique. Thus you can easily adapt your new telescope optimally to your wishes. Please do not forget to select the base for attaching the focuser to the tube. You can choose from our whole range. A few recommendations are given below:

UNCN2-G2 - TS 2" UNC Newtonian Crayford focuser - short

Economically priced 2" Crayford focuser for observing and photography with DSLR cameras. The short focuser needs only 75 mm optical path.

Item number of the necessary base: BAST-UNCN2G2 - please add to your order.



FTF2008BCR - Starlight Feather Touch 2" focuser - 20 mm draw tube travel

The best 2" focuser we know, for maximal stability without compromises. In addition, the focuser is very short, together with the base, it is only 50 mm heigh.

Item number of the necessary base: BA20CL-230mm - please add to your order.



Orion ACU-3S 3" Crayford focuser with M82x1 thread

The massive 3" focuser is our recommendation for astrophotographers who want to work with a 3" Newtonian corrector (N-AGK3, TS 3" Wynne or TeleVue VIP-3010.) These correctors are screwed to the M82 thread of the focuser.

Item number of the necessary base: NB240-ORACU3 - please add to your order.

We recommend three focus positions above the 2" tube of the focuser:

1. astrophotography with the standard coma correctors - 65 mm above the 2" tube (STANDARD Version)
That version is optimized for the standard correctors like the TS coma corrector, the GPU corrector, the Baader MPCC or the ASA Quattro. For visual use, you need to add the 2" extension tube - Art.Nr. TSV235.

2. astrophotographic use with the ASA 2" Reducer/corrector - 90 mm above the 2" tube
That position is ideal for the use of the ASA Reducer/corrector ASA2KORRR. The reducer brings the system up from f/4.5 to f/3.3.

3. Visual use - 35 mm above 2" tube
We recommend that version for visual use of the telescope. For this telescope line, we recommend the 58 mm secondary mirror. The 2" Paracorr VIP-2010 also works fine with this focus position.

The focus positions are calculated and achieved by changing the primary mirrors position. Of course you can also get other positions if you want. For expample if you want to use a 3" coma corrector. The three we mentioned are the most common ones.

Further customizable parts of the ONTC Newtonian telescopes:

If you order the instrument via our webshop, you can send us a notice in the text field below the payment methods. There is a textfield "Informations concerning your order" where you can tell us what you want to have. The alternative is dropping us an email : info@teleskop-service.de

Rings or bar directly connected to the tube - no change of the price:

The scope of delivery also includes rings with a flat base on both sides. According to your wish, we can also attach a dovetail bar (Losmandy or Vixen style) directly to the tube. If choosing that modification, the tube gets additional fibre layers where necessary.

Video of the assembly

TS has posted a video (text in German language) of the assembly of this telescope on YouTube:



You can also visit it via this link.

Assembly and collimation instructions

The telescope is delivered disassembled into several units for safety. The assembly and adjustment are not complicated, you can download the instructions in advance. The PDF can be found here.

Astrophotographic results obtained with this telescope on Astrobin

Here you can find some astrophotographs made with this telescope model: Link to Astrobin

General product video

Teleskop-Service has made an information video about the UNC and ONTC telescopes:

Astrophotographic results obtained with this telescope on Astrobin

Here you can find some astrophotographs made with this telescope model: Link to Astrobin

Customer images

Our ambassador Sophie Paulin (www.instagram.com/lyaphine, www.astrobin.com/users/Lyaphine) from near Augsburg is a trained photographer and started the hobby of astrophotography about 2 years ago. Here are three sample images:

Object: Bode´s Galaxy (M 81) and Cigar Galaxy (M 82)

Photographer: Sophie Paulin
Imaging Optics: TS-Optics 8" f/4,5 ONTC (ONTC809)
Focuser: Baader Diamond Steeltrack Focuser (BA2957230)
Focusing Motor: DeepSkyDad AF3 Focuser
Rotator: DeepSkyDad FieldRotator FR1
Imaging Corrector: TeleVue Paracorr Type 2 (VIP-2010)
Imaging Camera: ZWO ASI2600MC Pro (ASI2600MC-P)
Guiding Scope: TS-Optics 80 mm finder (TSFRE80T2)
Guiding Camera: ZWO ASI120MM Mini (ASI120mini)
Mount: iOptron CEM70 (C70A)
Software: Nighttime Imaging ´N´ Astronomy · PixInsight · APP · Affinity Photo · Adobe Lightroom Classic CC


Object: Iris Nebula (NGC 7023)

Photographer: Sophie Paulin
Imaging Optics: TS-Optics 8" f/4,5 ONTC (ONTC809)
Focuser: Baader Diamond Steeltrack Focuser (BA2957230)
Focusing Motor: DeepSkyDad AF3 Focuser
Rotator: DeepSkyDad FieldRotator FR1
Imaging Corrector: TeleVue Paracorr Type 2 (VIP-2010)
Imaging Camera: ZWO ASI2600MC Pro (ASI2600MC-P)
Guiding Scope: TS-Optics 80 mm finder (TSFRE80T2)
Guiding Camera: ZWO ASI120MM Mini (ASI120mini)
Mount: iOptron CEM70 (C70A)
Software: Nighttime Imaging ´N´ Astronomy · PixInsight · APP · Affinity Photo · Adobe Lightroom Classic CC


Object: Dumbbell Nebula (M 27)

Photographer: Sophie Paulin
Imaging Optics: TS-Optics 8" f/4,5 ONTC (ONTC809)
Focuser: Baader Diamond Steeltrack Focuser (BA2957230)
Focusing Motor: DeepSkyDad AF3 Focuser
Rotator: DeepSkyDad FieldRotator FR1
Imaging Corrector: TeleVue Paracorr Type 2 (VIP-2010)
Imaging Camera: ZWO ASI2600MC Pro (ASI2600MC-P)
Guiding Scope: TS-Optics 80 mm finder (TSFRE80T2)
Guiding Camera: ZWO ASI120MM Mini (ASI120mini)
Mount: iOptron CEM70 (C70A)
Software: Nighttime Imaging ´N´ Astronomy · PixInsight · APP · Affinity Photo · Adobe Lightroom Classic CC

Congratulations to our brand ambassador Sophie Paulin for these stunning images!

A new image by this customer

Here is a new image by Sophie Paulin:

Object: Rosebud Nebula (NGC 7129)

Photographer: Sophie Paulin
Imaging Optics: TS-Optics 8" f/4,5 ONTC (ONTC809)
Focuser: Baader Diamond Steeltrack Focuser (BA2957230)
Focusing Motor: DeepSkyDad AF3 Focuser
Rotator: DeepSkyDad FieldRotator FR1
Imaging Corrector: TeleVue Paracorr Type 2 (VIP-2010)
Imaging Camera: ZWO ASI2600MC Pro (ASI2600MC-P)
Exposure Times: 17 h Luminance, 14 h RGB, 50 h H-alpha
Guiding Scope: TS-Optics 80 mm finder (TSFRE80T2)
Guiding Camera: ZWO ASI120MM Mini (ASI120mini)
Mount: iOptron CEM70 (C70A)
Software: Nighttime Imaging ´N´ Astronomy · PixInsight · APP · Affinity Photo · Adobe Lightroom Classic CC

We congratulate Sophie Paulin on this impressive photo as well!

Photographs by a customer

Our customer Cody M. Looman from Durango (USA) is an astrophotographer, wildlife photographer and landscape photographer. Here are two sample images:

Object: The Hidden Galaxy (IC 342)

Photographer: Cody M. Looman from Durango (USA)
Imaging optics: TS-Optics 8" f/4.5 ONTC (ONTC809)
Focuser: Starlight FTF2008BCR Feather Touch 2" (FTF2008BCR)
Coma Corrector: TS-Optics NEWTONIAN Coma Corrector 1.0x Superflat 4-Element (TSGPU)
Filter Wheel: ZWO USB Filter Wheel for 7x2" Filters (ZWOEFW7X2)
Filters: Chroma LRGB Filter Set (CT271012M)
Imaging Camera: ZWO ASI2600MM Pro (ASI2600MM-P)
Off-Axis Guider: ZWO OAG-L (ZWO-OAG-L)
Guiding Camera: ZWO ASI290MM Mini (ASI290MINI)
Mount: Losmandy G11 GoTo (G11GLT)


Object: Boogeyman-Nebel (LDN 1622)

Photographer: Cody M. Looman from Durango (USA)
Imaging optics: TS-Optics 8" f/4.5 ONTC (ONTC809)
Focuser: Starlight FTF2008BCR Feather Touch 2" (FTF2008BCR)
Coma Corrector: TS-Optics NEWTONIAN Coma Corrector 1.0x Superflat 4-Element (TSGPU)
Filter Wheel: ZWO USB Filter Wheel for 7x2" Filters (ZWOEFW7X2)
Filters: Chroma LRGB Filter Set (CT271012M), Chroma 5 nm Narrowband Filters H-alpha, O-III, S-II (CT270022M, CT270072M, CT270102M)
Imaging Camera: ZWO ASI2600MM Pro (ASI2600MM-P)
Off-Axis Guider: ZWO OAG-L (ZWO-OAG-L)
Guiding Camera: ZWO ASI290MM Mini (ASI290MINI)
Mount: Losmandy G11 GoTo (G11GLT)

Congratulations to Cody Looman on these nice images!
