Rowan Astronomy AZ75 Alt-Azimuth Mount

Name: Rowan Astronomy AZ75 Alt-Azimuth Mount
Brand: Rowan Astronomy
SKU: 21531200a
Price: 956 EUR

This solid mount carries up to 15 kg on each side and can be moved by simple push-to.

Easy handling by push-to operation

No need for locking and unlocking the drives due to fricion clutches

Rigid and smooth design with high quality ball and taper bearings

Can be ordered with one of three common threads to attach to tripods

Manufacturer: Rowan Astronomy

Product number: 21531200a

EUR 956,00

incl. 19 % VAT (DE)

The VAT indicated refers to that applicable in Germany. After logging in, the VAT amount is adjusted to the applicable VAT of the stored delivery country. Therefore, the final price may vary accordingly.

excl. 6.95 € shipping costs (DE)

Please log in to calculate shipping costs to your country.

more details to the shipping costs ...

There are no reviews for this product

Roll over image to zoom in or klick it. The appropriate zoom factor ist adjustable with the mouse wheel.

Rowan Astronomy AZ75 Alt-Azimuth Mount

This solid mount carries up to 15 kg on each side and can be moved by simple push-to.

Easy handling by push-to operation

No need for locking and unlocking the drives due to fricion clutches

Rigid and smooth design with high quality ball and taper bearings

Can be ordered with one of three common threads to attach to tripods

Details..
Technical data..
In the box..
Manufacturer infos..
Safety informations..

Rowan Astronomy AZ75 Alt-Azimuth Mount

Features:

CNC machined and black anodised finished and fitted with stainless steel hardware

32 mm diameter aluminium axis shafts supported in high quality ball and taper bearings

Features included adjustable friction clutches on both axis allowing push-to tracking

Top elevation axis lock for eyepiece changes

Load capacity is up to 15 kg each side depending on scope length.

Mount weight is 4.1 kg.

Mount weight with 2 x DV saddles is 4.4 kg.

Mount base can be supplied with M12, M10 or 3/8" UNC tapped hole to attach to tripods.

AZ75 is compatible with AZ100 saddles.

The mount does not come with saddles, you can choose between 1 or 2 saddles for Vixen style dovetail bars.

The mount also does not come with a tripod, you can use one matching the thread you ordered the mount with.

Mount type:	Alt-azimuth mount
Load capacity:	up to 15 kg each side
Shafts:	32 mm aluminium axis shafts
Bearings:	Ball and taper bearings
Drive:	Manually by push-to (friction clutches)
Tripod connection:	M12 threaded hole, M10 threaded hole, or 3/8" UNC threaded hole
Mount weight:	4.1 kg
Mount weight with 2 x V saddles:	4.4 kg
