Fornax 105 GoTo Mount for telescopes up to 90 kg weight - for observatories

Fornax Equatorial GoTo Mounts for Astrophotography and Observation

The Fornax 105 German Equatorial Mount - the heavy-duty mount designed for precise positioning and tracking of large telescopes weighing up to 90 kg. Constructed with premium quality materials including aluminum alloy, bronze, and stainless steel, this mount is built to last for years to come. The worm and electric motor are enclosed in a sealed space, providing protection against dust and temperature fluctuations while requiring minimal maintenance. Thanks to the inner drive mechanism, this mount operates without any backlash, providing superior precision during observation. Upgrade your astronomy equipment with the Fornax 105 for a reliable and exceptional observing experience.

The worm and electric motor are located in an enclosed, sealed space, making it less sensitive to dust and temperature fluctuations and practically maintenance-free. Thanks to the ingenious solution of the inner drive mechanism, this telescope mount does not suffer from any backlash.

Exceptional Tracking
With the Fornax 105, you can enjoy exceptional tracking and high-precision imaging with ease. The typical periodic error when not guided is less than +/- 6 arc seconds, with one period on the worm gear lasting 7.5 minutes. When using auto guiding, the mount reacts immediately, so corrections are very fast and completely free of play. This makes the Fornax 105 the ultimate solution for astrophotography with a high quality/price ratio. Whether you are a beginner or a seasoned astronomer, the Fornax 105 is the perfect mount for capturing stunning celestial objects.

The MC5 GoTo controller with hand box

The control was developed by Ursa Minor for large mounts and is ideal for Fornax mounts. Of course, the control unit is delivered readily adjusted with the mount. About 50,000 objects are already contained in the database.

Power supply 12 V to 30 V - we recommend 24-30 Volt stabilized power supply

Maximum current consumption 2.5 A (controller only)

Computer connection - USB available

Autoguiderport ST4 level available

DSLR control (2.5 mm stereo jack) available

Safety informations: PDF Download
